Panasonic Wide Angle Zoom | 24-60mm f2.8 Lumix S Lens

AT A GLANCE

• F2.8 brightness throughout the zoom range
• Versatile coverage from 24mm wide-angle to 60mm standard
• Closest focusing distance is just 0.19m at 24-30mm / 0.33m at 60mm

• A compact and lightweight lens : φ 84.0 x 99.9mm / 544g
• Dust/Splash/Freeze resistant and fluorine coating

• LUMIX S series lens first: Switchable to control ring
• Equipped with a focus button assignable to shooting features
• Supports manual focus while zooming

• Fewer lens elements without compromising image quality
• Streamlined components while ensuring structural integrity
• Optimized performance from each lens group with minimal elements
• Prioritizing compactness, the telephoto end was set at 60mm

When the focus mode is set to AF, the focus ring can be used as a control ring.

The direction of ring rotation can be switched left or right.

Lens Construction  14 elements in 12 groups (3 aspherical lenses, 1 UED lens, 2 ED lenses)

Mount  L-Mount

Focal Length  f=24-60mm

Aperture Type  9 diaphragm blades / Circular aperture diaphragm

Maximum Aperture  F2.8

Minimum Aperture  F22

Closest Focusing Distance  0.19m/0.62ft (at focal length 24-30mm) / 0.33m/1.08ft (at focal length 60mm)

Maximum Magnification  0.30x (at focal length 30mm) (0.25x at focal length 24mm, 0.22x at focal length 60mm)

Diagonal Angle of View 84°(Wide) – 40°(Tele)

Dust and Splash Resistant  Yes*

Recommended Operating Temperature  -10? to 40?  (14? to 104?)

Filter Size  φ77mm

Max. Diameterφ  84.0mm / 3.31inch

Overall Length Approx. 99.9mm / 3.93inch  (from the tip of the lens to the base side of the lens mount)

Weight  Approx. 544g / 1.20lb (excluding lens cap, lens rear cap and lens hood)

Panasonic Lumix S 24-60mm f/2.8 Lens

• Front Lens Cap
• Rear Lens Cap
• Lens Hood
• Lens Bag
